- External cahassie: steel sheet painted in epoxy powder stove
- Front doors (No. 2) bi-laminate safety glass with hinge and equipped with key lock
- Tempered glass side windows for internal vision.
- Perforated shelves (No. 4) for the ascensional movement of the treated air, freely positioned at any height
- Double perforated back panel for intake for heavy vapors and cleaning of the cabin at any point
- Lower grids (No. 8) for ambient air intake with two prefilters synthetic lower with frame in galvanized steel, easily replaceable "drawer"
- Group filter replacement fast from front cabinet consists of:
* No. 1 CI200/B40 type active carbon filter (thickness 40 mm) for the adsorption of formaldehyde / glutaraldehyde (different filters on request)
* No. 1 HEPA filter efficiency of 99.995% at MPPS particles of 0.3 micrometers installed upstream from the carbon filter group above.
- Aspirant centrifugal motor fan, 355 W, with self-adjusting air flow by electronic card. With doors closed the fan works at reduced cycle (Energy Saver System)
- Pipe-fitting exhaust cylindrical trunk (collar), outer diameter 150 mm, for possible exhaust air channeling outside
- Interior lighting ceiling lamps using fluorescent lamps (28 W power with shock-proof/antiglare screen) witha keyboard command to switch light with doors open or closed.
- Lighting the work area:> 1000 lux
- Electronic board controlled by a last generation microprocessor
- Automatic adjustment of the speed of the air entering through the electronic card able to make up for:
* continuously changes of opening of cabinet doors;
* the progressive clogging of the pre-filters and HEPA filters for any, if installed;
* any voltage drop of the power supply;
* the presence of one or more players before the cabinet by reducing the air velocity to avoid turbulence in the storage area.
- Autoregulation exhaust flow for the adjustment of a single barrier frontal opening front doors or two windows at the same time
- Light and sound alarms preset for:
* clogging prefilters
* air speed low and relative
* filter clogging
* visual alarm on the display of the replacement of the filters installed (reset after replacement)
- Membrane keyboard with:
* bipolar switch 0/1 light
* aspirator button start
* button switch internal light
* UVC lamp switch button (optional) and operation timer
* enable button internal electric socket (optional)
* digital hour meter operational
* real time reading of the air speed in transit inside the cabinet on the digital display in m/sec
- Noise level: < 57 dB(A)
- Average speed incoming air: 0.30 m / sec (adjustable by the customer)
- Exhaust air flow: 750m3/h max
- Power installed: 410 W
- Electric power: 230V/50 Hz
- External dimensions: 1200 x 890 x 2210 mm (l x p x h)
- Internal useful dimensions: 1180 x 660 x 1400 mm (l x p x h)
- Weight: 330 kg |
